ioButton LoRa

The ioButton is a professional IoT panic button for people safety and emergency alerting in workplaces, facilities and industrial environments.

This is the LoRa version, designed for simple installation, long battery life, and minimal maintenance.

89.00 €

Specifications

LoRaWAN 1.0.4EU868, US915 and AU915 support

RGB LED ringVisual and vibration feedback

90 dBPiezo alarm

Up to 10 yearsBattery life*

Connectivity	LoRaWAN 1.0.4
Frequency regions	EU868, US915 and AU915; additional regions on request
Region switching	Software-controlled RF switch for 868 MHz and 915 MHz on the same device
Panic button	Red push button with Cherry MX tactile switch
Visual feedback	Full-colour RGB LED ring
Haptic feedback	Vibration motor
Audible alert	90 dB piezo alarm
Configuration	Over the air via LoRaWAN or via the ioTracker configurator app using Bluetooth 5.1
BLE beacon support	Scanning for iBeacon, AltBeacon and Eddystone; beacon filters and trigger actions
Firmware updates	Firmware over-the-air updates (FOTA); Wi-Fi 802.11 b/g/n, 2.4 GHz for firmware updates

Battery	User-replaceable ER14500 (AA), 2,400 mAh; e.g. Saft LS14500
Battery life	Up to 10 years, depending on configuration, usage and operating conditions
Dimensions	78 × 78 × 20.4 mm
Weight	70 g including battery
Ingress protection	IP40
Operating temperature	-20 °C to +65 °C
Mounting	Included detachable wall-mount bracket; installation using double-sided tape or screws
Custom branding	Customisable front sticker on request; dedicated surface for a customer label

LoRaWAN region

EU868, US915, AU915
